SEALING COMPLEXITY. Bioceramic use in Advanced Root Canal Anatomy. A true Middle Mesial & Middle Distal Canals Management!.

This case was referred to me due to a failed direct pulp capping.

CBCT scans demonstrated a highly complex canal configuration:

•Mesial root: three distinct canals (mesiobuccal, mesiolingual, and middle mesial)

•Distal root: three canals  (distobuccal, distolingual, and middle distal)

This complex anatomy was the main reason for the referral.

Starting with access cavity preparation, followed by removal of the pulp stone.

The access cavity was then modified using ultrasonic tips to enhance visualization and precision.

Coronal flaring was performed to eliminate inflamed tissue from the main canal and to achieve optimal straight-line access for better file control.

This video illustrates the troughing procedure that performed at a 3 mm sub-pulpal level within the mesial root system to identify the presence of a middle mesial canal.

Once the canal orifice was detected, negotiation was carefully continued using a size 08 K-file, followed by the establishment of a glide path and subsequent progression toward full instrumentation.

During the instrumentation of the middle mesial canal, extreme caution is required due to its characteristically narrow and delicate anatomy.

In this case, instrumentation was limited to a size 20, 0.04 taper.

Troughing and shaping of the Middle Distal Canal were performed following the same approach and techniques applied in the mesial system.

Master Cone Fit Evaluation

Distal Root System:

A notably wide isthmus was observed in the distal root. Clinically, it appeared as if there were four canals, however, shifted radiographs confirmed the presence of three independent canals, each with a separate apical foramen.

Mesial Root System:

The mesial root similarly contained three independent canals. The configuration and number of canals were confirmed using shifted radiographs, ensuring precise anatomical identification.

Successful endodontic treatment in complex root canal systems relies on enhanced disinfection. Comprehensive irrigation, combined with activation using various techniques, improves irrigant penetration and effectively removes debris and microbial contaminants from the entire root canal system.

In this case, the Hydraulic Condensation Technique was performed using a C-ROOT bioceramic sealer.

This technique was chosen because the sealer can penetrate intricate anatomical regions that gutta-percha alone cannot reach, effectively filling anastomoses and intercanal communications, and providing predictable three-dimensional obturation.

The procedure commenced with the injection of the C-ROOT bioceramic sealer.

Although the three canals had separate apical foramina, the presence of multiple anastomoses and intercanal communications allowed the sealer to flow through these pathways, resulting in a comprehensive 3D fill.

Obturation and immediate coronal seal

The final obturation demonstrated an impressive anatomical reproduction, with three canals fully obturated in the mesial root and three canals fully obturated in the distal root.

All intercanal communications and anastomoses were completely filled, resulting in a clear three-dimensional (3D) obturation pattern achieved using the C-Root bioceramic sealer alone.

The three-dimensional CBCT provided comprehensive visualization of the root canal system.

This favorable outcome was achieved using a technique that is simple, efficient, and does not require specialized equipment, yet reliably produced an optimal three-dimensional (3D) fill in a highly complex root canal anatomy.

Long-term success relies not only on optimal apical sealing of all canals, but equally on a durable coronal seal achieved through conservative preparation, accurate cementation, and proper functional restoration.

By addressing both aspects, the treatment outcome is optimized in terms of sealing ability, biomechanics, function, and long-term clinical prognosis.
